HASTI H.D.P.E. PIPES & FITTINGS

Salient Features of Hasti H.D.P.E. Pipes

1. C value 150 - least frictional loss - techno commercial gain.
2. Non Toxic, Microbial resistant and Food Grade.
3. Tough, impact resistant, flexible - can be coiled up to 125mm OD.
4. Lower weight (3 times lighter than Al, 8 times lighter than steel).
5. Excellent water hammer / surge characteristics.
6. Durable, long term working life —beyond 50 yrs.
7. High abrasion resistance & no corrosion/incrustation.
8. High stiffness : withstand long term internal pressure, static & dynamic loads when buried.
9. Resistance to ultraviolet and thermal degradation.
10. Temperature resistant (-40 deg C to 60 deg C).
11. Suitable for gas flow applications viz LPG/CNG etc.
12. Preferred Material of construction with techniques of HDD, pipe bursting, slip lining etc.
13. Jointing by heat fusion, electro fusion, socket fusion, compression, fittings, mechanical-joint couplings and flange joint.
14. Leak-proof fusion joints - strong as the pipe itself.
15. Fewer fittings required - Flexible PE pipe can be cold-bent in the field to follow contours easily reducing the need for fittings.
16. Ease in laying on hilly terrains. Low maintenance required.
17. Online tapping for gas and water connection possible.

Applications of Hasti H.D.P.E. Pipes

Agriculture and Horticulture HASTI pioneered concept of portable sprinkler with HDPE pipes with low cost patented quick coupling attachments. HASTI and RELPIPE pipes and fittings revolutionized the Indian agriculture market scenario since they have been developed considering the needs of Indian farmers. A wide variety of fittings and accessories are available to meet the varied demand. HASTI also offers innovative positive locking, innovative high pressure sustaining quick coupled pipes and fittings with accessories for Tea and Coffee plantations RELPI PE and HASTI sprinkler systems are economic, effective and efficient

1. Large, Medium and Small lift irrigation system from source
2. Agriculture Portable Sprinkler Systems
3. Tea and Coffee Irrigation System
4. Landscape Irrigation system
5. Agriculture flow irrigation main /sub main pipe lines
6. Drip Irrigation - Main & Sub main lines

1) Water Supply :

Transportation of portable water is one of the major problems faced by community in 21st century.HASTI,the largest manufacturer of HDPE pipes in the country devotes maximum of its production capacity in manufacturing of HDPE pipes used in transportation of portable water.In a span of three decades HASTI has supplied and installed more than 2,00,000 kms.of HASTI HDPE pipes for transportation of water to cater the needs of thirsty millions.

2) Chemical & Edible Transport :

Hasti HDPE pipes being chemically inert,offer total solution in handling corrosive chemical medium.The piping system can be designed up to 45°C with with operating pressure up to 6 kg/cm² using right grade of raw material for higher life expectancy.Acids/alkalis diluted or concentrated sulphuric acid,phosphoric acid,hydrochloric acid,fluric acid,aromatic acid,caustic soda,conveyance (pH 0 to 14)demands use ofHDPE pipelines.Edible oils,juices,pulp,salts,alcohol/beer conveyance piping system are few more applications.HASTI has executed inplant piping projects on turnkey basis for transportation of above chemicals in petrochemical,fertilizers & other chemical plants.

3) Effluent Collection & Disposal System :

Hasti HDPE pipes are absolutely inert to effluent in any pH range,offers an excellent techno-commercial proposition to design engineers for both collection of raw treated effluent,disposal of effluent over a long distance without any environmental problems.Hasti HDPE pipes offers safe & trouble free transportation of dangerous chemicals in effluent treatment plant(ETP) areas.Hasti HDPE pipes fully meet with the regulatory requirement of various Pollution Boards norms of Marine outfall systems based on HDPE pipes also helps in combatting industrial pollution for safe disposal of chemicals in the sea as per National Institute of Oceanography(NIO)requirement.

4) Submarine & Underwater Pipeline :

HASTI has experianced technical expertise for executing submarine & underwater pipeline carrying potable water/effluent disposal in to the sea,creek makes Hasti HDPE piping syatem an undisputed choice.Apart from this Hasti HDPE pipes are better choice for river crossing and nallha crossing.HASTI has executed various offshore piping jobs under most critical working conditions for effluent disposal in sea/estuary in various sizes up to 630mm OD for a length of more than 3 kms.

5) Slurry Transportation :

Hasti HDPE pipes being resilient in nature offers low wear of the inside surface resulting in increases in life span of the piping system while transporting abrasive slurries.It has been observed that under identical working conditions HDPE pipes have given 4-5 times longer life than conventional material.Hasti HDPE have proven their suitability for hydro transport of solids like iron/tin ore slurry,iron ore tailing slurry,coal slurry,cement slurry,fly ash and boiler ash as slurry.The conveyance of mud water/sand slurry of dredging can also be performed effectively through Hasti HDPE pipes.

Pipe Manufacturing Facilities - Hazira & Akola

Product Range

1. PE Pipe product range - 16 mm to 710 mm/ 2.5 kg to 16 kg, from PE 63/80/100 grade in various standards
2. X flow Coils for Water Supply
3. Sprinkler pipes, fittings and system accessories
4. PPR (Poly Propylene Random) Pipes and Fittings
5. Duct Pipe and accessories for Telecom sector
6. Gas Pipes
7. In house/ Outsourced moulded & fabricated fittings
8. Cable Ducting with innovative coupling system
9. Electro fusion and Compression Fittings *

Product Conformity standards:

1. IS: 4984:1995 High Density Polyethylene Pipes for Water Supply
2. IS: 14333 :1996 High Density Polyethylene Pipes for Sewerage & Effluent
3. IS: 14885:2001 Polyethylene (PE) Pipes for the supply of Gaseous fuels
4. IS: 14151 (Part I & 2) Irrigation equipment-Sprinkler pipes
5. Part I Polyethylene pipes
6. Part 2 Quick Coupled Polyethylene Pipes
7. DIN 8077/78 - Polypropylene Random Co - polymer (PP-R) pipes and fittings
8. ISO 4427:2007 - Plastics piping systems - Polyethylene (PE) pipes and fittings for water supply - Part 2: Pipes ISO 4437: 2007 - Buried Polyethylene (PE) pipes for the supply of gaseous fuels - Metric series - Specification DIN 8074: 1999 - Polyethylene (PE) pipes
9. EN 12201 -2:2003 - Plastics piping systems for water supply - Polyethylene (PE) - Part 2: Pipes TEC/ spec.GR/CDS/08/02, Nov 2004 - Telecom ducts

+ Our Engineering team will be happy to examine any special requirements.

Dust Supression System

Tailor made systems can be efffectively used for settlement of dust at haul roads,mineral loading platform, ore handling plants etc.
